Features
· Good mechanical and environmental characteristics.
· Flame retardant characteristics meet the requirements of relevant standards.
· The mechanical characteristics of jacket meet the requirements of relevant standards.
· Soft, flexible, easy to splice, and with big capacity data transmission.
· Meet various requirements of market and clients.
Application
· Used in indoor cabling.
· Used as access building cable.
· Used as interconnect lines of equipments,and used in optical connections in optical communication room and optical distribution frames.
· Used as pigtails and patch cords.
Options
· Fiber Type: G.652, G.655, G.657 single-mode fiber, A1a or A1b mulit-mode fiber, or other types of fiber.
· Jacket Material: Polyvinylchloride(PVC), Low smoke zero halogen(LSZH), Thermoplatic polyurethane(TPU), or other contracted material.
· Fiber Count: Total number of fibers in the cable.
· Jacket color: (including color of fiber)meets the requirements of relevant standards,or other contracted color.
· Cable Dimension: The nominal cable dimension or other contracted dimension.
· Delivery Length: 1KM or 2KM or other contracted length.
· Other Requirements: Other contracted special requests.
Specifications
Fiber
Count | Subunit
Count | Fiber Count Cable
in Each Unit | Dimension
(mm) | Cable Weight
(kg/km) | Tensile(N) | Crush
(N/100mm) | Min.bend Radius
(mm) | Range of Long
Temperature(°C) |
Long
Term | Short
Term | Long
Term | Short
Term | Dynamic | Static |
Miniature Indoor Cable II |
36 | 3 | 12 | 10.0 | 79 | 200 | 600 | 300 | 1000 | 20D | 10D |
|
48 | 4 | 12 | 10.0 | 80 | 200 | 600 | 300 | 1000 | 20D | 10D |
|
60 | 5 | 12 | 11.0 | 110 | 300 | 1000 | 300 | 1000 | 20D | 10D |
|
72 | 6 | 12 | 12.0 | 130 | 300 | 1000 | 300 | 1000 | 20D | 10D | -20°C ~ +60°C |
96 | 8 | 12 | 14.0 | 180 | 300 | 1000 | 300 | 1000 | 20D | 10D |
|
144 | 12 | 12 | 17.0 | 290 | 300 | 1000 | 300 | 1000 | 20D | 10D |
|
288 | 12 | 24 | 17.0 | 304 | 300 | 1000 | 300 | 1000 | 20D | 10D |
|
Note:1 D is outer diameter of the round tale
Note:2 The cable dimension and weight are in accordance with the tight-buffered fiber of 0.9mm outer diameter
Note:3 Theminimum bend radius(static)is 5D when G.657fiber is used
